Linear TW


Tuneable White Flexible LED Strip

By mixing the light distribution between the 2700k and 6500k high CRI LEDs it is possible to change the feel, warmth and vibrancy of a space. Using programming equipment it is possible to create human-centric lighting cycles and mimic circadian rhythms.

Pre-wired terminations at the end of each reel minimise soldering on site and provide for improved lead times.

Like all Colourbox products, excellent dimming is guaranteed.

Specifications

Constant Voltage 24v
LEDs/m 120+120
Cut Points 50mm
Output: 18w 1460lm
CRI: 95Ra
CCT: 6500K > 2700K
IP Rating: IP20 & IP65
Pre-wiring: 100mm cable at each end
Reel length: 5m/10m
Control: DALI DT8, Bluetooth

For exact specifications and details of relevant drivers and installation profiles please see our datasheet.




Linear TW Datasheet

Installation Manual
